KAESER - speed-controlled piston compressor
Type: i.Comp 8 TOWER T - Complete compressed air station - oil-free with 2x 40 liter compressed air tanks and refrigeration dryer
The i.Comp 8 is an oil-free piston compressor with a speed-controlled drive motor, two compressed air tanks, an integrated refrigeration dryer and the internal SIGMA CONTROL 2 control. Ideal for craft businesses, industry, workshops and laboratories. Made in Germany.
Type: i.Comp 8 TOWER T - Complete compressed air station - oil-free with 2x 40 liter compressed air tanks and refrigeration dryer
The i.Comp 8 is an oil-free piston compressor with a speed-controlled drive motor, two compressed air tanks, an integrated refrigeration dryer and the internal SIGMA CONTROL 2 control. Ideal for craft businesses, industry, workshops and laboratories. Made in Germany.
Technical data (volume flow and performance data according to ISO 1217:2009, Annex E)
- Flow rate at 6 bar, 2100 rpm: 404 l/min
- Flow rate at 11 bar, 1800 rpm: 291 l/min
- Max overpressure: 11 bar
- Total power consumption including dryer at 6 bar, 2100 rpm: 3.45 kW
- Total power consumption including dryer at 11 bar, 1800 rpm: 3.5 kW
- Speed range min./max.: 1000-2100 rpm
- Duty cycle: 100%
- Rated power drive motor: 3.1 kW
- Electrical supply: 380-480 V / 50-60 Hz
- Sound pressure level: 65 dB(A)
- Sound power level: 81 dB(A)
- Dimensions (W x D x H): 840 x 1130 x 1380 mm
- Mass: 254 kg
- Ambient temperature min./max.: +3/+45 °C
- Tank size: 2 x 40L
- Power consumption refrigeration dryer at ambient temperature +20°C, relative humidity 30%: 0.28 kW
- Pressure dew point at ambient temperature +20°C, rel. Humidity 30%: +3°C
- Refrigerant: R-513A
- Refrigerant charge: 0.22 kg
- Global warming potential GWP: 631
- CO2 equivalent: 0.14 t
Technical changes reserved.
Key product benefits of the KAESER i.Comp TOWER T piston compressor
Oil-free compressed air
The i.Comp delivers oil-free compressed air. That means there is no oil-laden condensate that needs to be disposed of. That protects the environment. Oil changes and oil checks are also no longer necessary, which results in low overall service costs. At the same time, the service life of the compressor increases.
Speed-controlled drive motor
In almost all cases, there is a fluctuating consumption profile for the compressed air. The frequency converter of the i.Comp enables the volume flow to be precisely adjusted to the current requirement, which means that pressure fluctuations are kept to a minimum. In comparison to a non-frequency-controlled compressor, switching cycles are largely avoided.
Control SIGMA CONTROL 2
The pressure can be set precisely on the integrated control. All operating, fault and maintenance messages are shown on the large display. All information can be forwarded to a higher-level controller via a SIGMA NETWORK interface.
Integrated refrigeration dryer
The refrigeration dryer with the new environmentally friendly refrigerant R-513A safely removes moisture from the compressed air. The standard ECO-DRAIN condensate drain removes the condensate from the system.
Key product benefits of the KAESER i.Comp TOWER T piston compressor
Oil-free compressed air
The i.Comp delivers oil-free compressed air. That means there is no oil-laden condensate that needs to be disposed of. That protects the environment. Oil changes and oil checks are also no longer necessary, which results in low overall service costs. At the same time, the service life of the compressor increases.
Speed-controlled drive motor
In almost all cases, there is a fluctuating consumption profile for the compressed air. The frequency converter of the i.Comp enables the volume flow to be precisely adjusted to the current requirement, which means that pressure fluctuations are kept to a minimum. In comparison to a non-frequency-controlled compressor, switching cycles are largely avoided.
Control SIGMA CONTROL 2
The pressure can be set precisely on the integrated control. All operating, fault and maintenance messages are shown on the large display. All information can be forwarded to a higher-level controller via a SIGMA NETWORK interface.
Integrated refrigeration dryer
The refrigeration dryer with the new environmentally friendly refrigerant R-513A safely removes moisture from the compressed air. The standard ECO-DRAIN condensate drain removes the condensate from the system.
